esxi主机需要升级内存，需要查看内存信息，ssh登陆执行

smbiosDump

[root@localhost:~] smbiosDump

Dumping live SMBIOS data!

  Type 218 Record: #55808

    Data 00: da 11 00 da b2 00 17 20 0e 10 03 ff ff 00 00 00

    Data 10: 00

  BIOS Info: #0

    Size: 0x0001a

    Vendor: "Dell Inc."

    Version: "2.6.3"

    Date: "01/18/2020"

    Start Address: 0xf0000

    ROM Size: 16384 kB

    Features: 0x0f03001f000059e99a90

      ISA supported

      PCI supported

      PnP supported

      BIOS flashable

      BIOS shadowing allowed

      CD boot supported

      Selectable boot supported

      EDD spec supported

      1.2MB Toshiba Japanese Floppy supported

      360kB Floppy supported

      1.2MB Floppy supported

      720kB Floppy supported

      8042 Keyboard Services supported

      Serial Services supported

      CGA/Mono Video supported

      ACPI supported

      USB Legacy supported

      BIOS Boot Spec supported

      F12 Network boot supported

      Enable targeted content distribution

      UEFI supported

    System BIOS release: 2.6

  System Info: #256

    Manufacturer: "Dell Inc."

    Product: "PowerEdge T440"

    Serial: "589K4W2"

    UUID: 3257344fc0b54b80391000384c4c4544

    Wake-up: 0x06 (Power Switch)

  Board Info: #512

    Manufacturer: "Dell Inc."

    Product: "00X7CK"

    Version: "A03"

    Serial: ".589K4W2.CNFCP0091U03MV."

  Chassis Info: #768

    Manufacturer: "Dell Inc."

    Serial: "589K4W2"

    Type: 0x11 (Main Server Chassis)

    Lock: present

    Bootup State: 0x03 (Safe)

    Power Supply State: 0x03 (Safe)

    Thermal State: 0x03 (Safe)

    Security Status: 0x02 (Unknown)

  Processor Info: #1024

    Payload length: 0x30

    Socket: "CPU1"

    Socket Type: 0x26 (Socket LGA2011)

    Socket Status: Populated

    Type: 0x03 (CPU)

    Family: 0xb3 (Xeon)

    Manufacturer: "Intel"

    Version: "Intel(R) Xeon(R) Bronze 3104 CPU @ 1.70GHz"

    Processor ID: 0xbfebfbff00050654

    Status: 0x01 (Enabled)

    Voltage: 1.8 V

    External Clock: 9600 MHz

    Max. Speed: 4000 MHz

    Current Speed: 1700 MHz

    L1 Cache: #1792

    L2 Cache: #1793

    L3 Cache: #1794

    Core Count: #6

    Core Enabled Count: #6

    Thread Count: #6

  Processor Info: #1025

    Payload length: 0x30

    Socket: "CPU2"

    Socket Type: 0x26 (Socket LGA2011)

    Socket Status: Populated

    Type: 0x03 (CPU)

    Family: 0xb3 (Xeon)

    Manufacturer: "Intel"

    Version: "Intel(R) Xeon(R) Bronze 3104 CPU @ 1.70GHz"

    Processor ID: 0xbfebfbff00050654

    Status: 0x01 (Enabled)

    Voltage: 1.8 V

    External Clock: 9600 MHz

    Max. Speed: 4000 MHz

    Current Speed: 1700 MHz

    L1 Cache: #1795

    L2 Cache: #1796

    L3 Cache: #1797

    Core Count: #6

    Core Enabled Count: #6

    Thread Count: #6

  Cache Info: #1792

    Level: L1

    State: Enabled

    Mode: 0x01 (Write Back)

    Location: 0x00 (Internal, Not Socketed)

    ECC: 0x04 (Parity)

    Type: 0x05 (Unified)

    Associativity: 0x07 (8-way Set-Associative)

    Max. Size: 384 kB

    Current Size: 384 kB

    Supported SRAM Types: 0x0002 (Unknown)

    Current SRAM Type: 0x0002 (Unknown)

  Cache Info: #1793

    Level: L2

    State: Enabled

    Mode: 0x01 (Write Back)

    Location: 0x00 (Internal, Not Socketed)

    ECC: 0x05 (Single-bit)

    Type: 0x05 (Unified)

    Associativity: 0x08 (16-way Set-Associative)

    Max. Size: 6144 kB

    Current Size: 6144 kB

    Supported SRAM Types: 0x0002 (Unknown)

    Current SRAM Type: 0x0002 (Unknown)

  Cache Info: #1794

    Level: L3

    State: Enabled

    Mode: 0x01 (Write Back)

    Location: 0x00 (Internal, Not Socketed)

    ECC: 0x05 (Single-bit)

    Type: 0x05 (Unified)

    Associativity: 0x06 (Fully Associative)

    Max. Size: 8448 kB

    Current Size: 8448 kB

    Supported SRAM Types: 0x0002 (Unknown)

    Current SRAM Type: 0x0002 (Unknown)

  Cache Info: #1795

    Level: L1

    State: Enabled

    Mode: 0x01 (Write Back)

    Location: 0x00 (Internal, Not Socketed)

    ECC: 0x04 (Parity)

    Type: 0x05 (Unified)

    Associativity: 0x07 (8-way Set-Associative)

    Max. Size: 384 kB

    Current Size: 384 kB

    Supported SRAM Types: 0x0002 (Unknown)

    Current SRAM Type: 0x0002 (Unknown)

  Cache Info: #1796

    Level: L2

    State: Enabled

    Mode: 0x01 (Write Back)

    Location: 0x00 (Internal, Not Socketed)

    ECC: 0x05 (Single-bit)

    Type: 0x05 (Unified)

    Associativity: 0x08 (16-way Set-Associative)

    Max. Size: 6144 kB

    Current Size: 6144 kB

    Supported SRAM Types: 0x0002 (Unknown)

    Current SRAM Type: 0x0002 (Unknown)

  Cache Info: #1797

    Level: L3

    State: Enabled

    Mode: 0x01 (Write Back)

    Location: 0x00 (Internal, Not Socketed)

    ECC: 0x05 (Single-bit)

    Type: 0x05 (Unified)

    Associativity: 0x06 (Fully Associative)

    Max. Size: 8448 kB

    Current Size: 8448 kB

    Supported SRAM Types: 0x0002 (Unknown)

    Current SRAM Type: 0x0002 (Unknown)

  Port Connector: #2048

    Type: 0x10 (USB)

    External Designator: "Back USB port 6"

    External Connector: 0x12 (Access Bus [USB])

  Port Connector: #2049

    Type: 0x10 (USB)

    External Designator: "Back USB port 5"

    External Connector: 0x12 (Access Bus [USB])

  Port Connector: #2050

    Type: 0x10 (USB)

    External Designator: "Back USB port 4"

    External Connector: 0x12 (Access Bus [USB])

  Port Connector: #2051

    Type: 0x10 (USB)

    External Designator: "Back USB port 3"

    External Connector: 0x12 (Access Bus [USB])

  Port Connector: #2052

    Type: 0x10 (USB)

    Internal Designator: "Internal USB port 1"

    Internal Connector: 0x12 (Access Bus [USB])

  Port Connector: #2053

    Type: 0x10 (USB)

    External Designator: "Front USB port 1"

    External Connector: 0x12 (Access Bus [USB])

  Port Connector: #2054

    Type: 0x10 (USB)

    External Designator: "Back USB port 1"

    External Connector: 0x12 (Access Bus [USB])

  Port Connector: #2055

    Type: 0x10 (USB)

    External Designator: "Front USB port 2"

    External Connector: 0x12 (Access Bus [USB])

  Port Connector: #2056

    Type: 0x10 (USB)

    External Designator: "Back USB port 2"

    External Connector: 0x12 (Access Bus [USB])

  Port Connector: #2057

    Type: 0x1c (Video Port)

    External Designator: "Video port 1"

    External Connector: 0x07 (DB-15 pin female)

  Port Connector: #2058

    Type: 0x09 (Serial Port 16550A Compatible)

    External Designator: "Serial port 1"

    External Connector: 0x08 (DB-9 pin male)

  Port Connector: #2059

    Type: 0x1f (Network Port)

    External Designator: "1"

    External Connector: 0x0b (RJ-45)

  Port Connector: #2060

    Type: 0x1f (Network Port)

    External Designator: "1"

    External Connector: 0x0b (RJ-45)

  System Slot: #2304

    Designation: "PCIe Slot 1"

    Type: 0xb1 (PCI Express Gen 3)

    Bus Width: 0x0a (x4)

    Status: 0x03 (Available)

    Length: 0x04 (Long)

    Slot ID: 1

    Characteristics: 0x0104 (3.3 V, PME#)

  System Slot: #2305

    Designation: "PCIe Slot 2"

    Type: 0xb1 (PCI Express Gen 3)

    Bus Width: 0x0a (x4)

    Status: 0x03 (Available)

    Length: 0x04 (Long)

    Slot ID: 2

    Characteristics: 0x0104 (3.3 V, PME#)

  System Slot: #2306

    Designation: "PCIe Slot 3"

    Type: 0xb1 (PCI Express Gen 3)

    Bus Width: 0x0d (x16)

    Status: 0x03 (Available)

    Length: 0x04 (Long)

    Slot ID: 3

    Characteristics: 0x0104 (3.3 V, PME#)

  System Slot: #2307

    Designation: "PCIe Slot 4"

    Type: 0xb1 (PCI Express Gen 3)

    Bus Width: 0x0b (x8)

    Status: 0x04 (In Use)

    Length: 0x04 (Long)

    Slot ID: 4

    Characteristics: 0x0104 (3.3 V, PME#)

  System Slot: #2308

    Designation: "PCIe Slot 5"

    Type: 0xb1 (PCI Express Gen 3)

    Bus Width: 0x0b (x8)

    Status: 0x03 (Available)

    Length: 0x04 (Long)

    Slot ID: 5

    Characteristics: 0x0104 (3.3 V, PME#)

  OEM Strings: #2816

    Dell System

    5[0000]

    14[1]

    26[0]

    17[AE6D316A2B65D02B]

    17[220707FD30B2AF20]

    18[0]

    19[1]

    19[1]

  System Config Options (Jumpers & Switches) #3072:

    NVRAM_CLR: Clear user settable NVRAM areas and set defaults

    PWRD_EN: Close to enable password

  Language Info: #3328

    Languages: en|US|iso8859-1

    Current: en|US|iso8859-1

  Physical Memory Array: #4096

    Use: 0x03 (System memory)

    Location: 0x03 (Motherboard)

    Slots: 16

    Max. Size: 1024 GB

    ECC: 0x06 (Multi-bit)

  Memory Device: #4352

    Location: "A1"

    Manufacturer: "00CE063200CE"

    Serial: "29061F8C"

    Asset Tag: "031842A0"

    Part Number: "M393A4K40BB2-CTD"

    Memory Array: #4096

    Form Factor: 0x09 (DIMM)

    Type: 0x1a (DDR4)

    Type Detail: 0x2080 (Synchronous, Registered)

    Data Width: 64 bits (+8 ECC bits)

    Size: 32 GB

    Speed: 2666 MHz

  Memory Device: #4353

    Location: "A2"

    Manufacturer: "00CE00B300CE"

    Serial: "41049984"

    Asset Tag: "02184151"

    Part Number: "M393A4K40CB2-CTD"

    Memory Array: #4096

    Form Factor: 0x09 (DIMM)

    Type: 0x1a (DDR4)

    Type Detail: 0x2080 (Synchronous, Registered)

    Data Width: 64 bits (+8 ECC bits)

    Size: 32 GB

    Speed: 2666 MHz

  Memory Device: #4354

    Location: "A3"

    Memory Array: #4096

    Form Factor: 0x02 (Unknown)

    Type: 0x02 (Unknown)

    Data Width: 0 bits

    Size: No Memory Installed

  Memory Device: #4355

    Location: "A4"

    Memory Array: #4096

    Form Factor: 0x02 (Unknown)

    Type: 0x02 (Unknown)

    Data Width: 0 bits

    Size: No Memory Installed

  Memory Device: #4356

    Location: "A5"

    Memory Array: #4096

    Form Factor: 0x02 (Unknown)

    Type: 0x02 (Unknown)

    Data Width: 0 bits

    Size: No Memory Installed

  Memory Device: #4357

    Location: "A6"

    Memory Array: #4096

    Form Factor: 0x02 (Unknown)

    Type: 0x02 (Unknown)

    Data Width: 0 bits

    Size: No Memory Installed

  Memory Device: #4358

    Location: "A7"

    Memory Array: #4096

    Form Factor: 0x02 (Unknown)

    Type: 0x02 (Unknown)

    Data Width: 0 bits

    Size: No Memory Installed

  Memory Device: #4359

    Location: "A8"

    Memory Array: #4096

    Form Factor: 0x02 (Unknown)

    Type: 0x02 (Unknown)

    Data Width: 0 bits

    Size: No Memory Installed

  Memory Device: #4360

    Location: "A9"

    Memory Array: #4096

    Form Factor: 0x02 (Unknown)

    Type: 0x02 (Unknown)

    Data Width: 0 bits

    Size: No Memory Installed

  Memory Device: #4361

    Location: "A10"

    Memory Array: #4096

    Form Factor: 0x02 (Unknown)

    Type: 0x02 (Unknown)

    Data Width: 0 bits

    Size: No Memory Installed

  Memory Device: #4362

    Location: "B1"

    Manufacturer: "00CE063200CE"

    Serial: "35061F8C"

    Asset Tag: "031842A0"

    Part Number: "M393A4K40BB2-CTD"

    Memory Array: #4096

    Form Factor: 0x09 (DIMM)

    Type: 0x1a (DDR4)

    Type Detail: 0x2080 (Synchronous, Registered)

    Data Width: 64 bits (+8 ECC bits)

    Size: 32 GB

    Speed: 2666 MHz

  Memory Device: #4363

    Location: "B2"

    Manufacturer: "00CE00B300CE"

    Serial: "410C52C3"

    Asset Tag: "02184151"

    Part Number: "M393A4K40CB2-CTD"

    Memory Array: #4096

    Form Factor: 0x09 (DIMM)

    Type: 0x1a (DDR4)

    Type Detail: 0x2080 (Synchronous, Registered)

    Data Width: 64 bits (+8 ECC bits)

    Size: 32 GB

    Speed: 2666 MHz

  Memory Device: #4364

    Location: "B3"

    Memory Array: #4096

    Form Factor: 0x02 (Unknown)

    Type: 0x02 (Unknown)

    Data Width: 0 bits

    Size: No Memory Installed

  Memory Device: #4365

    Location: "B4"

    Memory Array: #4096

    Form Factor: 0x02 (Unknown)

    Type: 0x02 (Unknown)

    Data Width: 0 bits

    Size: No Memory Installed

  Memory Device: #4366

    Location: "B5"

    Memory Array: #4096

    Form Factor: 0x02 (Unknown)

    Type: 0x02 (Unknown)

    Data Width: 0 bits

    Size: No Memory Installed

  Memory Device: #4367

    Location: "B6"

    Memory Array: #4096

    Form Factor: 0x02 (Unknown)

    Type: 0x02 (Unknown)

    Data Width: 0 bits

    Size: No Memory Installed

  Memory Array Mapping: #4864

    Memory Array: #4096

    Partition Width: 2

    Start Address: 0x00000000

    End Address: 0x80000000

  Memory Array Mapping: #4865

    Memory Array: #4096

    Partition Width: 2

    Start Address: 0x0000000100000000

    End Address: 0x0000002080000000

  Type 32 Record: #8192

    Data 00: 20 0b 00 20 00 00 00 00 00 00 00

  Type 38 Record: #9728

    Data 00: 26 12 00 26 01 20 20 ff a9 0c 00 00 00 00 00 00

    Data 10: 4a 0a

  Type 41 Record: #10496

    Data 00: 29 0b 00 29 01 85 01 00 00 04 00

    String 1: "Embedded NIC 1"

  Type 41 Record: #10497

    Data 00: 29 0b 01 29 01 85 02 00 00 04 01

    String 1: "Embedded NIC 2"

  Type 41 Record: #10498

    Data 00: 29 0b 02 29 01 83 01 00 00 03 00

    String 1: "Embedded Video"

  Type 177 Record: #45312

    Data 00: b1 0c 00 b1 02 02 00 00 00 00 00 00

  Type 208 Record: #53248

    Data 00: d0 10 00 d0 03 0b fe 00 cb 07 00 00 00 01 00 00

  Type 210 Record: #53760

    Data 00: d2 0c 00 d2 f8 02 03 03 06 80 04 05

  Type 212 Record: #54272

    Data 00: d4 1b 00 d4 70 00 71 00 00 00 00 00 5c 00 78 fe

    Data 10: 01 5d 00 78 fe 00 ff ff ff ff ff

  Type 216 Record: #55296

    Data 00: d8 09 00 d8 01 02 00 f0 03

    String 1: "Matrox"

    String 2: "{* Content TBD *}"

  Type 222 Record: #56832

    Data 00: de 10 00 de 00 80 00 00 19 03 25 15 13 03 00 01

  Type 225 Record: #57600

    Data 00: e1 0d 00 e1 01 01 00 04 00 02 01 04 00

    String 1: "CPU.Socket.1"

    String 2: "CPU.Socket.2"

  Type 225 Record: #57601

    Data 00: e1 45 01 e1 01 01 00 11 00 02 01 11 00 03 02 11

    Data 10: 00 04 03 11 00 05 04 11 00 06 05 11 00 07 06 11

    Data 20: 00 08 07 11 00 09 08 11 00 0a 09 11 00 0b 0a 11

    Data 30: 00 0c 0b 11 00 0d 0c 11 00 0e 0d 11 00 0f 0e 11

    Data 40: 00 10 0f 11 00

    String 1: "DIMM.Socket.A1"

    String 2: "DIMM.Socket.A2"

    String 3: "DIMM.Socket.A3"

    String 4: "DIMM.Socket.A4"

    String 5: "DIMM.Socket.A5"

    String 6: "DIMM.Socket.A6"

    String 7: "DIMM.Socket.A7"

    String 8: "DIMM.Socket.A8"

    String 9: "DIMM.Socket.A9"

    String 10: "DIMM.Socket.A10"

    String 11: "DIMM.Socket.B1"

    String 12: "DIMM.Socket.B2"

    String 13: "DIMM.Socket.B3"

    String 14: "DIMM.Socket.B4"

    String 15: "DIMM.Socket.B5"

    String 16: "DIMM.Socket.B6"

推荐本站淘宝优惠价购买喜欢的宝贝:

本文链接：https://hqyman.cn/post/3845.html 非本站原创文章欢迎转载，原创文章需保留本站地址！

休息一下~~
