HCIBench 是一个HCI超融合基础设施基准测试工具，它本质上是围绕流行且经过验证的开源基准测试工具（Vdbench 和 Fio）的自动化包装器，可以更轻松地跨 HCI 集群进行自动化测试。HCIBench 旨在以一致且可控的方式简化和加速客户 POC 性能测试。该工具完全自动化部署测试虚拟机、协调工作负载运行、聚合测试结果、性能分析和收集必要数据以进行故障排除的端到端过程。
HCIBench 不仅是专为 vSAN 设计的基准测试工具，还可用于评估 vSphere 环境中各种超融合基础架构存储的性能。
HCIBench 项目由 Chen Wei 及其团队构建，除了托管在 VMware by Broadcom Flings 网站，现在主要在 Github 进行更新。
HCIBench 使用方法请查看HCIBench User Guide，或者可以参考 使用HCIBench工具对vSAN超融合进行性能测试 这篇文章。
升级路径
当前版本 HCIBench 2.8.2
目标版本 HCIBench 2.8.3
升级条件
HCIBench 虚拟机需正常运行
HCIBench 虚拟机连接互联网
升级过程
1.使用root用户ssh登录至 HCIBench 虚拟机的shell命令行。
2.运行下面的任意命令下载并升级 HCIBench 版本。
tdnf install -y git && git clone https://github.com/vmware-labs/hci-benchmark-appliance.git && sh hci-benchmark-appliance/HCIBench/upgrade.sh
cd /root/ && wget https://github.com/vmware-labs/hci-benchmark-appliance/archive/refs/heads/main.zip && unzip main.zip && sh hci-benchmark-appliance-main/HCIBench/upgrade.sh
3.升级过程。
################################################## ## Welcome to HCIBench 2.8.2 ## # # To add a DNS, please edit file ## /etc/systemd/resolved.conf or # # /etc/systemd/network/eth0.network ## ##################################################root@photon-HCIBench [ ~ ]# root@photon-HCIBench [ ~ ]# tdnf install -y git && git clone https://github.com/vmware-labs/hci-benchmark-appliance.git && sh hci-benchmark-appliance/HCIBench/upgrade.shRefreshing metadata for: 'VMware Photon Linux 3.0 (x86_64) Updates'Refreshing metadata for: 'VMware Photon Extras 3.0 (x86_64)'Refreshing metadata for: 'VMware Photon Linux 3.0 (x86_64)'photon 2498249 100%
Upgrading:
git x86_64 2.35.6-1.ph3 photon-updates 22.04M 23110472
Total installed size: 22.04M 23110472
Downloading:
git 10853382 100%
Testing transaction
Running transaction
Installing/Updating: git-2.35.6-1.ph3.x86_64
Removing: git-2.23.3-3.ph3.x86_64
Complete!
Cloning into 'hci-benchmark-appliance'...
remote: Enumerating objects: 1382, done.
remote: Counting objects: 100% (215/215), done.
remote: Compressing objects: 100% (164/164), done.
remote: Total 1382 (delta 115), reused 92 (delta 49), pack-reused 1167
Receiving objects: 100% (1382/1382), 344.80 MiB | 13.01 MiB/s, done.
Resolving deltas: 100% (377/377), done.
Updating files: 100% (1103/1103), done.
Checking required commands
Command is installed: gem
Command is installed: python3
Command is installed: pip3
Command is installed: tar
All required commands available
Removing old files and backing up config files...
Removing gems
Gem 'rvc' is not installed
Gem 'rbvmomi' is not installed
Backing up files
Copied /opt/automation/conf/perf-conf.yaml to /tmp/conf
Copied /opt/automation/fio-param-files/fio-8vmdk-100ws-4k-70rdpct-100randompct-4threads-50compress-50dedupe to /tmp/fio-param-files
Copied /opt/automation/conf/key.bin to /tmp/conf
Copied /opt/automation/tmp/tvm.yaml to /tmp/tmp
Copied /opt/automation/logs/192.168.32.238-diskinit.log to /tmp/logs
Removing files
Archive: /root/hci-benchmark-appliance/HCIBench/pkgs/vm-template/disk-0.vmdk.zip
inflating: /root/hci-benchmark-appliance/HCIBench/pkgs/vm-template/disk-0.vmdk
Copying new worker VM template
Installing fioconfig
Removing previous version(s)
zip_safe flag not set; analyzing archive contents...
fioconfig.__pycache__.__main__.cpython-37: module references __file__
fioconfig.__pycache__.fioclocksources.cpython-37: module MAY be using inspect.getframeinfo
fioconfig.__pycache__.fiocontinueonerror.cpython-37: module MAY be using inspect.getframeinfo
fioconfig.__pycache__.fioiogenine.cpython-37: module MAY be using inspect.getframeinfo
fioconfig.__pycache__.fiojob.cpython-37: module MAY be using inspect.getframeinfo
fioconfig.__pycache__.fiopercentagerandom.cpython-37: module MAY be using inspect.getframeinfo
fioconfig.__pycache__.fiorandomgenerator.cpython-37: module MAY be using inspect.getframeinfo
fioconfig.__pycache__.fiorateiops.cpython-37: module MAY be using inspect.getframeinfo
fioconfig.__pycache__.fiorateprocess.cpython-37: module MAY be using inspect.getframeinfo
fioconfig.__pycache__.fioreadwrite.cpython-37: module MAY be using inspect.getframeinfo
fioconfig.__pycache__.fiosize.cpython-37: module MAY be using inspect.getframeinfo
fioconfig.__pycache__.fiosizeunit.cpython-37: module MAY be using inspect.getframeinfo
Fioconfig installed
Moving Utility to ~/
Install pip2
Upgrading:
python-pip noarch 18.0-4.ph3 photon-updates 7.38M 7740930
Total installed size: 7.38M 7740930
Downloading:
python-pip 2268346 100%
Testing transaction
Running transaction
Installing/Updating: python-pip-18.0-4.ph3.noarch
Removing: python-pip-18.0-3.ph3.noarch
Complete!
install nfs utils
Installing:
keyutils x86_64 1.5.11-1.ph3 photon-updates 153.92k 157614
libnfsidmap x86_64 2.3.3-8.ph3 photon-updates 131.83k 134990
libevent x86_64 2.1.12-1.ph3 photon-updates 774.34k 792920
rpcbind x86_64 1.2.5-1.ph3 photon 92.85k 95077
nfs-utils x86_64 2.3.3-8.ph3 photon-updates 1.18M 1235951
Total installed size: 2.30M 2416552
Downloading:
keyutils 72226 100%
libnfsidmap 71610 100%
libevent 359086 100%
rpcbind 52345 100%
nfs-utils 583937 100%
Testing transaction
Running transaction
Installing/Updating: rpcbind-1.2.5-1.ph3.x86_64
changed ownership of '/var/lib/rpcbind' from root:root to root:sys
Installing/Updating: libevent-2.1.12-1.ph3.x86_64
Installing/Updating: libnfsidmap-2.3.3-8.ph3.x86_64
Installing/Updating: keyutils-1.5.11-1.ph3.x86_64
Installing/Updating: nfs-utils-2.3.3-8.ph3.x86_64
Complete!
Created symlink /etc/systemd/system/multi-user.target.wants/nfs-server.service → /lib/systemd/system/nfs-server.service.
Created symlink /etc/systemd/system/multi-user.target.wants/rpcbind.service → /lib/systemd/system/rpcbind.service.
Created symlink /etc/systemd/system/sockets.target.wants/rpcbind.socket → /lib/systemd/system/rpcbind.socket.
install pip2 pkgs
Traceback (most recent call last):
File "/usr/bin/pip2", line 11, in <module>
load_entry_point('pip==18.0', 'console_scripts', 'pip2')()
File "/usr/lib/python2.7/site-packages/pkg_resources/__init__.py", line 484, in load_entry_point return get_distribution(dist).load_entry_point(group, name)
File "/usr/lib/python2.7/site-packages/pkg_resources/__init__.py", line 2707, in load_entry_point return ep.load()
File "/usr/lib/python2.7/site-packages/pkg_resources/__init__.py", line 2325, in load return self.resolve()
File "/usr/lib/python2.7/site-packages/pkg_resources/__init__.py", line 2331, in resolve
module = __import__(self.module_name, fromlist=['__name__'], level=0)
File "/usr/lib/python2.7/site-packages/pip/_internal/__init__.py", line 42, in <module>
from pip._internal import cmdoptions
File "/usr/lib/python2.7/site-packages/pip/_internal/cmdoptions.py", line 16, in <module>
from pip._internal.index import (
ImportError: cannot import name FormatControl
Installing RVC
Replacing tomcat file...
Stopping Tomcat
Removing old web app
Copying new web app
Starting Tomcat
Creating automation part and restoring config files...
Deploying gems...
Successfully installed ipaddress-0.8.3
Parsing documentation for ipaddress-0.8.3
Done installing documentation for ipaddress after 0 seconds
1 gem installed
Setting file permissions
Folder: /opt/automation
Setting: /opt/automation/cleanup-vm-in-folder.sh
Setting: /opt/automation/cleanup-vm.sh
Setting: /opt/automation/deploy-vms.sh
Setting: /opt/automation/generate-vdb-param-file.sh
Setting: /opt/automation/io-test.sh
Setting: /opt/automation/is-test-finished.sh
Setting: /opt/automation/kill-all-in-one-testing.sh
Setting: /opt/automation/kill-deploy-vm.sh
Setting: /opt/automation/kill-io-test.sh
Setting: /opt/automation/kill-vmdk-warmup.sh
Setting: /opt/automation/pre-validate-config.sh
Setting: /opt/automation/start-testing.sh
Setting: /opt/automation/vdb-process.sh
Setting: /opt/automation/warm-up-disk.sh
Folder: /opt/automation/lib
Setting: /opt/automation/lib/vmkstatsCollect.sh
Setting: /opt/automation/lib/vmkstats_postprocess.sh
Setting: /opt/automation/lib/vscsi-stats-cleanup.sh
Setting: /opt/automation/lib/vscsi-stats-setup.sh
Setting: /opt/automation/lib/all-in-one-testing.rb
Setting: /opt/automation/lib/cleanup-tvm-in-folder-org.rb
Setting: /opt/automation/lib/cleanup-tvm-in-folder.rb
Setting: /opt/automation/lib/cleanup-tvm.rb
Setting: /opt/automation/lib/cleanup-vm-in-folder.rb
Setting: /opt/automation/lib/cleanup-vm.rb
Setting: /opt/automation/lib/cleanup-vm.test.rb
Setting: /opt/automation/lib/collectSupportBundle.rb
Setting: /opt/automation/lib/collectVmkstats.rb
Setting: /opt/automation/lib/deploy-tvm.rb
Setting: /opt/automation/lib/deploy-vms.rb
Setting: /opt/automation/lib/disk-warm-up.rb
Setting: /opt/automation/lib/drop-cache.rb
Setting: /opt/automation/lib/easy-run.rb
Setting: /opt/automation/lib/generate_report.rb
Setting: /opt/automation/lib/getCpuUsage.rb
Setting: /opt/automation/lib/getPCpuUsage.rb
Setting: /opt/automation/lib/getRamUsage.rb
Setting: /opt/automation/lib/get-tvm-ip.rb
Setting: /opt/automation/lib/get-vm-ip.rb
Setting: /opt/automation/lib/get-vsan-info.rb
Setting: /opt/automation/lib/get-xls-fio.rb
Setting: /opt/automation/lib/get-xls-vdbench.rb
Setting: /opt/automation/lib/io-test.rb
Setting: /opt/automation/lib/ossl_wrapper_cli_commands.rb
Setting: /opt/automation/lib/ossl_wrapper_cli_parser.rb
Setting: /opt/automation/lib/ossl_wrapper_cli.rb
Setting: /opt/automation/lib/ossl_wrapper.rb
Setting: /opt/automation/lib/ossl_wrapper_util.rb
Setting: /opt/automation/lib/parseFioResult.rb
Setting: /opt/automation/lib/parseSupportBundle.rb
Setting: /opt/automation/lib/parseVdbResult.rb
Setting: /opt/automation/lib/prep-host-vsan-debug.rb
Setting: /opt/automation/lib/pre-validation.rb
Setting: /opt/automation/lib/reboot-vms.rb
Setting: /opt/automation/lib/run_telegraf.rb
Setting: /opt/automation/lib/rvc-util.rb
Setting: /opt/automation/lib/start-testing.rb
Setting: /opt/automation/lib/stop_all_telegraf.rb
Setting: /opt/automation/lib/test.rb
Setting: /opt/automation/lib/timetest.rb
Setting: /opt/automation/lib/util.rb
Setting: /opt/automation/lib/validate_subnets.rb
Setting: /opt/automation/lib/vm-health-check.rb
Folder: /opt/automation/lib/tests
Setting: /opt/automation/lib/tests/test_ossl_wrapper_cli_parser.rb
Setting: /opt/automation/lib/tests/test_ossl_wrapper_cli.rb
Setting: /opt/automation/lib/tests/test_ossl_wrapper.rb
Removing unecessary files
Folder: /opt/automation
Deleting: /opt/automation/tmp/.gitignore
Deleting: /opt/automation/vdbench-param-files/.gitignore
Deleting: /opt/automation/fio-param-files/.gitignore
Folder: /opt/output
Deleting: /opt/output/results/.DONT_TOUCH/docker/overlay2/7b55714a918ac035fe9d807a5234135f5697d3baddf56d8025808ec21fa89066/merged/usr/share/grafana/public/img/icons/.gitignore
Deleting: /opt/output/results/.DONT_TOUCH/docker/overlay2/7b55714a918ac035fe9d807a5234135f5697d3baddf56d8025808ec21fa89066/merged/usr/share/grafana/public/lib/.gitignore
Deleting: /opt/output/results/.DONT_TOUCH/docker/overlay2/bc35c8d62c3bc516922278a97c52dc7676d1649ab4ac3acbb61b3d7a20370eef/diff/opt/statsd/.gitignore
Deleting: /opt/output/results/.DONT_TOUCH/docker/overlay2/5c48fa6be24b102d9fb1e5c551da9f019955be615d6764d2016bb2b766d134ef/diff/usr/share/grafana/public/img/icons/.gitignore
Deleting: /opt/output/results/.DONT_TOUCH/docker/overlay2/5c48fa6be24b102d9fb1e5c551da9f019955be615d6764d2016bb2b766d134ef/diff/usr/share/grafana/public/lib/.gitignore
Folder: /opt/vmware/rvc/
Deleting: /opt/vmware/rvc/.gitignore
Removing git repository
Starting services...
reseting containers
58f63c54e445
0789cf393ca8
20d57ce22bdd
58f63c54e445
0789cf393ca8
20d57ce22bdd
Untagged: grafana-render:latest
Deleted: sha256:abf3ddeed8468dca789626cc0e2b78b0969d1bdf0a8ee3b40bd29fcff2f7e879
Deleted: sha256:fb4b1696f46921c2284ef43e779e34bd8c80c70dc30d650bc675116d96e839a0
Deleted: sha256:3cec585f7288a5593988a8fe1fbea1460d25d14f0edfc9faaf84ea2cdbdffff7
Deleted: sha256:241a73ccc00d6d5a8edb5b7729d3500dad9c2a62f4bd9c1e77b7f788ced7a65f
Deleted: sha256:5e7ad82e11ebb9644e79c0b408a749780111b30db512c958c77fc8d44e280b06
Deleted: sha256:3926df2b072155db3cf857d5e743218fd55019c5e862346317a8a100464ca20f
Deleted: sha256:69b267f3db88def695aa9a18893a92918d5117ca4637b24ca7060f9a3bda7264
Deleted: sha256:13e01086cfb6c1ca771a8de9081479b162e14129fc69f99e104634a0d3bc5c45
Deleted: sha256:1abdd551aa4193b63eb923b9e6bc8ea6628a032ae7a1f226eb6b307094f1c167
Deleted: sha256:cb21e7df21cd146d139e1fd2fe17caea062dc65a0fdef0f8890c7ff4d1b82cb6
Deleted: sha256:18c09b19d0102a1b3245e68b41f5ce69071f4d00584bb6d9c64be4f1880b8d4f
Deleted: sha256:83de5c1c6c596d58d3cbb380f2141605e19daf699aa8dde556871751ed7854dc
Deleted: sha256:1244f499e5997eaaf54286fea5e1d92d398bdacd6855e72423dd883e7ae0819e
Deleted: sha256:b173d406329bbd4710a402c4bb246a99a23e9ad5edce30c5a4042bbf5cae5114
Untagged: grafana/grafana:8.3.11
Untagged: grafana/grafana@sha256:966deb3459ac310152c0f6e1863a61426c453dc7f93c0a740d5b2c6b72b1b78d
Deleted: sha256:b48f3cb1b3cd3c5b507670440f7200a193a231b411024f8d6c7b3509a4aa61a9
Deleted: sha256:af6fa8a324b8cf32364492b627f26c9646a2987c830b5e2a67bcc30842ddc9d0
Deleted: sha256:25a239b28086161d822814e3fd7bd2f1380d5bb8a728afafded31d625adcc91e
Deleted: sha256:1cf9aa3e0d12e090404a43ed9d12bfef87ffffeb3c6a362c555770724958e265
Deleted: sha256:d48ff97a0c2b40c13f7ad11975fa20680da4b8fdbf22d5f0e2d5f192693b4c50
Deleted: sha256:2272bd377b495b23eb0f91c4e374ccaa999e5a599c52439a7e619d83d65762bf
Deleted: sha256:acdee0639fabec8dcdd93d09207e4b715cf00bcc02f3db99560671dbdba98700
Deleted: sha256:57876368c59b9267dce139df6dbbaf34b1ae0950450edc1c98b65c5d73b00922
Deleted: sha256:d5dbd9db75cb90409d0f42e82922247dcd48406ca45ee99c8fc98a87a5c22157
Deleted: sha256:a48e983127384c94ddd732bd902d892eb591a9c55922d41be2aefec4e139fd6b
Deleted: sha256:34d5ebaa5410d2ab4154bbd7c3c99c385ec509eb9c1d03d5486aff01bbd618c5
Untagged: influxdb:1.8.1-alpine
Untagged: influxdb@sha256:32dbb22a7a1f0d3be2a034cc7aac0bd43d68066b4375d0d2c8f745072df9f438
Deleted: sha256:38a3d14e43adecbd4ae14a5ab30bf9b0ab7edfeaa1ddb6b94224cdad972b8d98
Deleted: sha256:e1b71bc5953899c1a63e74454f99a0f3b9c69b78e941f3a832dd8795232cb545
Deleted: sha256:f91c04b008f3a03234cef7bfac1ec95e8a496772fd4d51ff6612497524cadf8a
Deleted: sha256:40cf23fecd3b6a06745d5075f3e9216d98cbd74c2cd2e3238bfcbb73cf787ff1
Deleted: sha256:6d8aacb146ce36d4ec23ed79204b568631c50eb4d56b97fc3461e16cab883488
Deleted: sha256:882b894fb8d8e312fd09db099b7d0826b8e2b07d08a3ea64b188bd3caff7ea37
Deleted: sha256:199f90ceca5db3276bfa47cb62dd53b52d478291e7a457e477fee5892b893298
Deleted: sha256:89ae5c4ee501a09c879f5b58474003539ab3bb978a553af2a4a6a7de248b5740
Untagged: graphiteapp/graphite-statsd:1.1.5-10
Untagged: graphiteapp/graphite-statsd@sha256:520d4f446b79cf969f3b9e30e5a49bc3d78092fc620469c280a12e52039f1f08
Deleted: sha256:1d7b81067e37934de60c2988ed68e6b749cc5e1c9c22072803f813a6cef90411
Deleted: sha256:fdad0c518bcbdc36683f6b6dff510a6a871313025f684206a967e63ddb2259f8
Deleted: sha256:afd019be619f489c8cce5e4a59f0eee20d5fd00624b3bd71f9044be0dfbd0baa
Deleted: sha256:5f75414d8d0d3c3f00219f800c4b6ffe6d52af761ffda27fb421870d7a28ad18
Deleted: sha256:767f936afb51c8a3ad9a96592a4be092048bb70f2ca410028a0b3f64b826acbb
Total reclaimed space: 0B
Total reclaimed space: 0B
Deleted Volumes: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 reclaimed space: 1.143GB
Total reclaimed space: 0B
Total reclaimed space: 0B
Unable to find image 'graphiteapp/graphite-statsd:1.1.5-10' locally
1.1.5-10: Pulling from graphiteapp/graphite-statsd
169185f82c45: Pull complete
1cc33baf7a2e: Pull complete
01d19f4f4984: Pull complete
5bdb248cffcb: Pull complete
Digest: sha256:520d4f446b79cf969f3b9e30e5a49bc3d78092fc620469c280a12e52039f1f08
Status: Downloaded newer image for graphiteapp/graphite-statsd:1.1.5-10
652baf6791ff15aeddb2b17ec9b120ac17d2adca8426e74065fd6e0e139843bd
Unable to find image 'influxdb:1.8.1-alpine' locally
1.8.1-alpine: Pulling from library/influxdb
31603596830f: Pull complete
321996f3080d: Pull complete
c9984b0a6973: Pull complete
dac116993ab1: Pull complete
42a5fc5379a9: Pull complete
b3f48eac3660: Pull complete
0e23b94f7fd3: Pull complete
Digest: sha256:32dbb22a7a1f0d3be2a034cc7aac0bd43d68066b4375d0d2c8f745072df9f438
Status: Downloaded newer image for influxdb:1.8.1-alpine
696e26d3d7c2e608b1468d42170848ee395578e316aa379babfa2a2dd2b4e346
Sending build context to Docker daemon 387.9MB
Step 1/13 : ARG GRAFANA_VERSION="8.3.11"Step 2/13 : FROM grafana/grafana:${GRAFANA_VERSION}8.3.11: Pulling from grafana/grafana
9621f1afde84: Pull complete
cd882b2ca95f: Pull complete
945c243dab30: Pull complete
643b565d3665: Pull complete
46e247b7143e: Pull complete
65d19ddb998d: Pull complete
47b452094ad0: Pull complete
ce176baa82ca: Pull complete
f2b56f6ccde4: Pull complete
4f02d02c7535: Pull complete
Digest: sha256:966deb3459ac310152c0f6e1863a61426c453dc7f93c0a740d5b2c6b72b1b78d
Status: Downloaded newer image for grafana/grafana:8.3.11
---> b48f3cb1b3cd
Step 3/13 : USER root
---> Running in 88c68dc27fc8
Removing intermediate container 88c68dc27fc8
---> d4a7d1a8ac92
Step 4/13 : ARG GF_INSTALL_IMAGE_RENDERER_PLUGIN="false"
---> Running in 11b6c1c78a31
Removing intermediate container 11b6c1c78a31
---> d0c421f6b0f4
Step 5/13 : ARG GF_GID="0"
---> Running in f8e295139ae5
Removing intermediate container f8e295139ae5
---> f069def35cbc
Step 6/13 : ENV GF_PATHS_PLUGINS="/var/lib/grafana-plugins"
---> Running in b35c1e65f473
Removing intermediate container b35c1e65f473
---> bcf41dbe06ea
Step 7/13 : RUN mkdir -p "$GF_PATHS_PLUGINS" && chown -R grafana:${GF_GID} "$GF_PATHS_PLUGINS"
---> Running in 927ceaa6aa4f
Removing intermediate container 927ceaa6aa4f
---> 6854418e67b0
Step 8/13 : RUN if [ $GF_INSTALL_IMAGE_RENDERER_PLUGIN = "true" ]; then echo "http://dl-cdn.alpinelinux.org/alpine/v3.14/community" >> /etc/apk/repositories && echo "http://dl-cdn.alpinelinux.org/alpine/v3.14/main" >> /etc/apk/repositories && echo "http://dl-cdn.alpinelinux.org/alpine/edge/testing" >> /etc/apk/repositories && apk --no-cache upgrade && apk add --no-cache udev ttf-opensans chromium && rm -rf /tmp/* && rm -rf /usr/share/grafana/tools/phantomjs; fi
---> Running in 590bfe2c4e6a
fetch https://dl-cdn.alpinelinux.org/alpine/v3.15/main/x86_64/APKINDEX.tar.gz
fetch https://dl-cdn.alpinelinux.org/alpine/v3.15/community/x86_64/APKINDEX.tar.gz
fetch http://dl-cdn.alpinelinux.org/alpine/v3.14/community/x86_64/APKINDEX.tar.gz
fetch http://dl-cdn.alpinelinux.org/alpine/v3.14/main/x86_64/APKINDEX.tar.gz
fetch http://dl-cdn.alpinelinux.org/alpine/edge/testing/x86_64/APKINDEX.tar.gz
(1/9) Upgrading musl (1.2.2-r7 -> 1.2.2-r9)
(2/9) Upgrading ca-certificates-bundle (20220614-r0 -> 20230506-r0)
(3/9) Upgrading libcrypto1.1 (1.1.1q-r0 -> 1.1.1w-r1)
(4/9) Upgrading libssl1.1 (1.1.1q-r0 -> 1.1.1w-r1)
(5/9) Upgrading ca-certificates (20220614-r0 -> 20230506-r0)
(6/9) Upgrading musl-utils (1.2.2-r7 -> 1.2.2-r9)
(7/9) Upgrading libcom_err (1.46.4-r0 -> 1.46.6-r0)
(8/9) Upgrading krb5-libs (1.19.3-r0 -> 1.19.4-r0)
(9/9) Upgrading tzdata (2022a-r0 -> 2023c-r0)
Executing busybox-1.34.1-r7.trigger
Executing ca-certificates-20230506-r0.trigger
Executing glibc-bin-2.30-r0.trigger
/usr/glibc-compat/sbin/ldconfig: /usr/glibc-compat/lib/ld-linux-x86-64.so.2 is not a symbolic linkOK: 31 MiB in 36 packages
fetch https://dl-cdn.alpinelinux.org/alpine/v3.15/main/x86_64/APKINDEX.tar.gz
fetch https://dl-cdn.alpinelinux.org/alpine/v3.15/community/x86_64/APKINDEX.tar.gz
fetch http://dl-cdn.alpinelinux.org/alpine/v3.14/community/x86_64/APKINDEX.tar.gz
fetch http://dl-cdn.alpinelinux.org/alpine/v3.14/main/x86_64/APKINDEX.tar.gz
fetch http://dl-cdn.alpinelinux.org/alpine/edge/testing/x86_64/APKINDEX.tar.gz
(1/130) Installing libxau (1.0.9-r0)
(2/130) Installing libmd (1.0.3-r0)
(3/130) Installing libbsd (0.11.3-r1)
(4/130) Installing libxdmcp (1.1.3-r0)
(5/130) Installing libxcb (1.14-r2)
(6/130) Installing libx11 (1.7.3.1-r1)
(7/130) Installing libxext (1.3.4-r0)
(8/130) Installing libice (1.0.10-r0)
(9/130) Installing libuuid (2.37.4-r0)
(10/130) Installing libsm (1.2.3-r0)
(11/130) Installing libxt (1.2.1-r0)
(12/130) Installing libxmu (1.1.3-r0)
(13/130) Installing xset (1.2.4-r0)
(14/130) Installing xprop (1.2.5-r0)
(15/130) Installing xdg-utils (1.1.3-r0)
(16/130) Installing eudev-libs (3.2.11_pre1-r0)
(17/130) Installing pkgconf (1.8.1-r0)
(18/130) Installing libffi (3.4.2-r1)
(19/130) Installing libblkid (2.37.4-r0)
(20/130) Installing libmount (2.37.4-r0)
(21/130) Installing pcre (8.45-r1)
(22/130) Installing glib (2.70.5-r0)
(23/130) Installing xz-libs (5.2.5-r1)
(24/130) Installing libxml2 (2.9.14-r2)
(25/130) Installing shared-mime-info (2.1-r2)
(26/130) Installing hicolor-icon-theme (0.17-r1)
(27/130) Installing libjpeg-turbo (2.1.2-r0)
(28/130) Installing libpng (1.6.37-r1)
(29/130) Installing libwebp (1.2.2-r2)
(30/130) Installing zstd-libs (1.5.0-r0)
(31/130) Installing tiff (4.4.0-r4)
(32/130) Installing gdk-pixbuf (2.42.8-r0)
(33/130) Installing gtk-update-icon-cache (2.24.33-r0)
(34/130) Installing libxcomposite (0.4.5-r0)
(35/130) Installing libxfixes (6.0.0-r0)
(36/130) Installing libxrender (0.9.10-r3)
(37/130) Installing libxcursor (1.2.0-r0)
(38/130) Installing libxdamage (1.1.5-r1)
(39/130) Installing libxi (1.8-r0)
(40/130) Installing libxinerama (1.1.4-r1)
(41/130) Installing libxrandr (1.5.2-r1)
(42/130) Installing atk (2.36.0-r0)
(43/130) Installing libxtst (1.2.3-r3)
(44/130) Installing dbus-libs (1.12.26-r0)
(45/130) Installing at-spi2-core (2.42.0-r0)
(46/130) Installing at-spi2-atk (2.38.0-r0)
(47/130) Installing expat (2.5.0-r0)
(48/130) Installing brotli-libs (1.0.9-r5)
(49/130) Installing libbz2 (1.0.8-r1)
(50/130) Installing freetype (2.11.1-r2)
(51/130) Installing fontconfig (2.13.1-r4)
(52/130) Installing pixman (0.40.0-r4)
(53/130) Installing cairo (1.16.0-r5)
(54/130) Installing cairo-gobject (1.16.0-r5)
(55/130) Installing avahi-libs (0.8-r5)
(56/130) Installing gmp (6.2.1-r1)
(57/130) Installing nettle (3.7.3-r0)
(58/130) Installing p11-kit (0.24.0-r1)
(59/130) Installing libtasn1 (4.18.0-r1)
(60/130) Installing libunistring (0.9.10-r1)
(61/130) Installing gnutls (3.7.1-r2)
(62/130) Installing cups-libs (2.3.3-r8)
(63/130) Installing libepoxy (1.5.9-r0)
(64/130) Installing fribidi (1.0.11-r0)
(65/130) Installing graphite2 (1.3.14-r0)
(66/130) Installing harfbuzz (3.0.0-r2)
(67/130) Installing libxft (2.3.4-r0)
(68/130) Installing pango (1.48.10-r0)
(69/130) Installing wayland-libs-client (1.19.0-r1)
(70/130) Installing wayland-libs-cursor (1.19.0-r1)
(71/130) Installing wayland-libs-egl (1.19.0-r1)
(72/130) Installing xkeyboard-config (2.34-r0)
(73/130) Installing libxkbcommon (1.3.1-r0)
(74/130) Installing gtk+3.0 (3.24.30-r0)
Executing gtk+3.0-3.24.30-r0.post-install
(75/130) Installing libfontenc (1.1.4-r0)
(76/130) Installing mkfontscale (1.2.1-r1)
(77/130) Installing ttf-opensans (1.10-r1)
Executing ttf-opensans-1.10-r1.post-install
(78/130) Installing libogg (1.3.5-r0)
(79/130) Installing libstdc++ (10.3.1_git20211027-r0)
(80/130) Installing flac (1.3.4-r0)
(81/130) Installing alsa-lib (1.2.5.1-r1)
(82/130) Installing libatomic (10.3.1_git20211027-r0)
(83/130) Installing sdl2 (2.0.16-r4)
(84/130) Installing aom-libs (3.2.0-r0)
(85/130) Installing libass (0.15.2-r0)
(86/130) Installing libdav1d (0.9.2-r0)
(87/130) Installing lame (3.100-r0)
(88/130) Installing opus (1.3.1-r1)
(89/130) Installing libgomp (10.3.1_git20211027-r0)
(90/130) Installing soxr (0.1.3-r2)
(91/130) Installing libsrt (1.4.2-r1)
(92/130) Installing libssh (0.9.6-r1)
(93/130) Installing libtheora (1.1.1-r16)
(94/130) Installing v4l-utils-libs (1.22.1-r1)
(95/130) Installing libpciaccess (0.16-r0)
(96/130) Installing libdrm (2.4.109-r0)
(97/130) Installing libva (2.13.0-r0)
(98/130) Installing libvdpau (1.4-r0)
(99/130) Installing vidstab (1.1.0-r1)
(100/130) Installing libvorbis (1.3.7-r0)
(101/130) Installing libvpx (1.10.0-r0)
(102/130) Installing vulkan-loader (1.2.196-r0)
(103/130) Installing x264-libs (20210613-r0)
(104/130) Installing x265-libs (3.5-r0)
(105/130) Installing xvidcore (1.3.7-r1)
(106/130) Installing ffmpeg-libs (4.4.1-r2)
(107/130) Installing libevent (2.1.12-r4)
(108/130) Installing mesa (21.2.6-r0)
(109/130) Installing wayland-libs-server (1.19.0-r1)
(110/130) Installing mesa-gbm (21.2.6-r0)
(111/130) Installing lcms2 (2.12-r1)
(112/130) Installing nspr (4.32-r0)
(113/130) Installing sqlite-libs (3.36.0-r0)
(114/130) Installing nss (3.78.1-r0)
(115/130) Installing libasyncns (0.8-r1)
(116/130) Installing libltdl (2.4.6-r7)
(117/130) Installing orc (0.4.32-r0)
(118/130) Installing libsndfile (1.0.31-r1)
(119/130) Installing speexdsp (1.2.0-r0)
(120/130) Installing tdb-libs (1.4.5-r0)
(121/130) Installing libpulse (15.0-r2)
(122/130) Installing re2 (2021.11.01-r0)
(123/130) Installing snappy (1.1.9-r1)
(124/130) Installing libgpg-error (1.42-r1)
(125/130) Installing libgcrypt (1.9.4-r0)
(126/130) Installing libxslt (1.1.35-r0)
(127/130) Installing chromium (99.0.4844.84-r0)
(128/130) Installing udev-init-scripts (35-r0)
Executing udev-init-scripts-35-r0.post-install
(129/130) Installing kmod-libs (29-r2)
(130/130) Installing eudev (3.2.11_pre1-r0)
Executing busybox-1.34.1-r7.trigger
Executing glib-2.70.5-r0.trigger
Executing shared-mime-info-2.1-r2.trigger
Executing gdk-pixbuf-2.42.8-r0.trigger
Executing gtk-update-icon-cache-2.24.33-r0.trigger
Executing fontconfig-2.13.1-r4.trigger
Executing mkfontscale-1.2.1-r1.trigger
Executing glibc-bin-2.30-r0.trigger
/usr/glibc-compat/sbin/ldconfig: /usr/glibc-compat/lib/ld-linux-x86-64.so.2 is not a symbolic linkExecuting eudev-3.2.11_pre1-r0.trigger
OK: 312 MiB in 166 packages
Removing intermediate container 590bfe2c4e6a
---> 2e6022d33c60
Step 9/13 : USER grafana
---> Running in d84728bfd3c0
Removing intermediate container d84728bfd3c0
---> 67da2cdd41ca
Step 10/13 : ENV GF_PLUGIN_RENDERING_CHROME_BIN="/usr/bin/chromium-browser"
---> Running in 007a10e32e99
Removing intermediate container 007a10e32e99
---> f5d33b2c8d8d
Step 11/13 : RUN if [ $GF_INSTALL_IMAGE_RENDERER_PLUGIN = "true" ]; then grafana-cli --pluginsDir "$GF_PATHS_PLUGINS" --pluginUrl https://github.com/grafana/grafana-image-renderer/releases/latest/download/plugin-linux-x64-glibc-no-chromium.zip plugins install grafana-image-renderer; fi
---> Running in 0ee9488fc387
? Downloaded grafana-image-renderer v3.10.4 zip successfully
Please restart Grafana after installing plugins. Refer to Grafana documentation for instructions if necessary.
Removing intermediate container 0ee9488fc387
---> d3806314f9ef
Step 12/13 : ARG GF_INSTALL_PLUGINS=""
---> Running in c996e36dd7d4
Removing intermediate container c996e36dd7d4
---> 3876730eba15
Step 13/13 : RUN if [ ! -z "${GF_INSTALL_PLUGINS}" ]; then OLDIFS=$IFS; IFS=','; for plugin in ${GF_INSTALL_PLUGINS}; do IFS=$OLDIFS; if expr match "$plugin" '.*\;.*'; then pluginUrl=$(echo "$plugin" | cut -d';' -f 1); pluginInstallFolder=$(echo "$plugin" | cut -d';' -f 2); grafana-cli --pluginUrl ${pluginUrl} --pluginsDir "${GF_PATHS_PLUGINS}" plugins install "${pluginInstallFolder}"; else grafana-cli --pluginsDir "${GF_PATHS_PLUGINS}" plugins install ${plugin}; fi done fi
---> Running in b7608dc5d384
Removing intermediate container b7608dc5d384
---> d879f9c81971
Successfully built d879f9c81971
Successfully tagged grafana-render:latest
9c07731d9e70100b02c7892da6876a400afc40231bd3edd4719068ba57593d58
{"datasource":{"id":1,"uid":"fqLYCaLIk","orgId":1,"name":"Graphite","type":"graphite","typeLogoUrl":"","access":"proxy","url":"http://172.17.0.1:8020","password":"","user":"","database":"","basicAuth":false,"basicAuthUser":"","basicAuthPassword":"","withCredentials":false,"isDefault":true,"jsonData":{"graphiteVersion":"1.1"},"secureJsonFields":{},"version":1,"readOnly":false},"id":1,"message":"Datasource added","name":"Graphite"}{"datasource":{"id":2,"uid":"9gPYC-YSz","orgId":1,"name":"InfluxDB","type":"influxdb","typeLogoUrl":"","access":"proxy","url":"http://172.17.0.1:8086","password":"","user":"","database":"telegraf","basicAuth":false,"basicAuthUser":"","basicAuthPassword":"","withCredentials":false,"isDefault":false,"jsonData":{"httpMode":"GET"},"secureJsonFields":{},"version":1,"readOnly":false},"id":2,"message":"Datasource added","name":"InfluxDB"}[OK] Installation Successful
root@photon-HCIBench [ ~ ]#4.验证版本。
cat /etc/issue
推荐本站淘宝优惠价购买喜欢的宝贝:
本文链接：https://hqyman.cn/post/6965.html 非本站原创文章欢迎转载，原创文章需保留本站地址！
微信支付宝扫一扫，打赏作者吧～休息一下~~
官码2024000195号
萌ICP备20248119号
